Download Xiaomi Mi 5 Firmware (gemini): Fix Bootloop, Lag & Software Issues
This comprehensive guide provides direct download links for the stock firmware flash files and step-by-step instructions to restore your Xiaomi Mi 5 (gemini). Whether you need to reset your phone, fix bootloop issues, bypass password locks, resolve device freezing, or address other software problems, this guide has you covered. The Mi 5, featuring a Snapdragon 820 chipset, a 5.15-inch FHD display, and a 3000mAh battery, is a flagship device from 2016 known for its sleek design and high performance. Note: This article is for the gemini codename (Mi 5), not to be confused with other Xiaomi models like Mi 5s (capricorn), Mi 5s Plus (natrium), or Mi Note 2 (scorpio).
⚠️ Essential Pre-Flash Checklist
Flashing can lead to errors if not done correctly. Complete this checklist to ensure a smooth process. All data will be wiped, so a backup is critical.
- ✅ Full Data Backup: Save photos, contacts, and files to Mi Cloud, Google Drive, or a PC to prevent data loss.
- ✅ Charged Battery: Ensure your Mi 5 has at least 60% battery to avoid interruptions during flashing.
- ✅ Windows PC: The Mi Flash Tool requires a Windows operating system.
- ✅ Original USB Cable: Use a high-quality USB-C cable for a stable connection to your PC.
- ✅ Unlocked Bootloader: Flashing requires an unlocked bootloader. Use the official Mi Unlock Tool (expect a 7-15 day waiting period).
- ✅ Required Software: Install the latest Mi Flash Tool and Xiaomi USB Drivers.
Understanding the Firmware: Types and Regions
Selecting the correct firmware is crucial to avoid bricking your Mi 5 (gemini). The gemini codename is specific to the Mi 5 with the Snapdragon 820 processor, distinct from Mi 5s (capricorn, Snapdragon 821) or Mi 5s Plus (natrium, Snapdragon 821).
- Fastboot ROM (.tgz): A full factory image for Mi Flash Tool, ideal for unbricking or reverting to stock MIUI.
- Recovery ROM (.zip): Used with custom recoveries like TWRP for installing custom ROMs like Xiaomi.eu.
- Region Codes:
- CNXM: China version, optimized for local networks but may lack Google Play services.
- MIXM: Global version with Google services and multi-language support.
- EUXM: Xiaomi.eu version, a debloated MIUI ROM with Google services and multi-language support.
Official Firmware Downloads for Mi 5 (gemini)
These firmware files are sourced from Xiaomi’s official servers or trusted repositories for reliability and security. Ensure you download ROMs for the gemini codename to avoid compatibility issues.
| Region | MIUI Version | Android | Release Date | Download Link |
|---|---|---|---|---|
| China (CNXM) | V10.2.1.0.OAACNXM | 8.0 | 2018-12-24 | Fastboot ROM |
| Global (MIXM) | V10.2.2.0.OAAMIXM | 8.0 | 2019-01-15 | Fastboot ROM |
| EU (EUXM) | V11.0.2.0.OAACNXM | 8.0 | Unknown | Recovery ROM |
TWRP Recovery for Mi 5 (gemini)
To flash custom ROMs or recovery ROMs via TWRP, install the TWRP custom recovery specific to the Mi 5 (gemini).
- TWRP Recovery:
- TWRP-3.7.0_9-0-gemini – Official TWRP image from TWRP’s site, recommended for the latest compatibility.
- TWRP-3.3.0-0511-XIAOMI5-CN – An older TWRP version for gemini. For updates, check TWRP’s official site or XDA Forums.
How to Install TWRP:
- Download the TWRP .img file (preferably TWRP-3.7.0_9-0 for latest compatibility) or extract the .rar file for TWRP-3.3.0-0511 to obtain
recovery.img. - Boot your Mi 5 into Fastboot mode (Volume Down + Power).
- Connect to your PC and open a command prompt.
- Flash TWRP by running:
fastboot flash recovery recovery.img. - Boot into recovery:
fastboot boot recovery.img.
Warning: Do not use a TWRP image for other devices (e.g., capricorn or natrium), as it will brick your gemini device. Verify that the TWRP version is gemini-specific.
Recommended Custom ROMs
The Mi 5 (gemini) benefits from strong custom ROM support due to its Snapdragon 820 chipset, offering flagship-grade performance. The Xiaomi.eu ROM provides a refined MIUI experience, while other custom ROMs extend Android versions.
- Xiaomi.eu ROM: V11.0.2.0.OAACNXM Based on Android 8.0 – Offers a lightweight, optimized MIUI experience with Google services.
- LineageOS: Check LineageOS or XDA Forums for builds like LineageOS 17.1 (Android 10) or 18.1 (Android 11), which are well-supported for gemini due to its high-performance chipset.
- Pixel Experience: Check Pixel Experience or XDA for builds like Pixel Experience 10 or 11, offering a Google Pixel-like interface with enhanced features.
How to Flash: Step-by-Step Instructions
Choose the flashing method based on your firmware type: Fastboot for official .tgz files or Recovery for custom .zip files.
Method 1: The Fastboot Method (Official Stock ROMs)
- Unzip the Firmware: Extract the .tgz file using 7-Zip to obtain a folder with an “images” subfolder and flash scripts.
- Launch Mi Flash Tool: Open the Mi Flash Tool with administrator privileges on your Windows PC.
- Enter Fastboot Mode: Power off your Mi 5, then press and hold Volume Down + Power until the Fastboot logo appears.
- Connect to PC: Plug your phone into your PC using a USB-C cable.
- Load Firmware: In Mi Flash Tool, click “select” and choose the extracted firmware folder. Click “refresh” to detect your device.
- Choose Flash Option: Select “clean all” for a complete reset (recommended for stability). Avoid “clean all and lock” unless you’re certain of the ROM’s region compatibility.
- Start Flashing: Click “flash” and wait 5-10 minutes. Do not disconnect the phone.
Troubleshooting Tip: If Mi Flash Tool fails to detect your Mi 5, try reinstalling the Xiaomi USB Drivers or switching to a USB 2.0 port for better connectivity.
Method 2: The Recovery Method (Custom ROMs)
- Install TWRP: Ensure TWRP is installed using the provided TWRP-3.7.0_9-0-gemini image for best compatibility, or the older TWRP-3.3.0-0511.
- Transfer ROM: Copy the .zip ROM file (e.g., Xiaomi.eu) to your phone’s internal storage or an SD card.
- Boot into Recovery: Power off your phone, then press Volume Up + Power until the TWRP logo appears.
- Wipe Data: In TWRP, go to “Wipe” > “Advanced Wipe” and select Dalvik/ART Cache, Cache, and Data. Swipe to confirm.
- Install ROM: Return to the main menu, tap “Install,” select the .zip file, and swipe to flash.
- Reboot: Reboot to system after installation completes.
After the Flash: First Boot and Setup
The first boot after flashing may take 10-15 minutes as the system initializes. Don’t interrupt if it seems stuck on the Mi logo. Once booted, follow the setup wizard and restore your data from your backup.
Device-Specific Q&A for the Mi 5 (gemini)
- Q1: Why does my Mi 5 experience system lag? A: System lag can result from bloatware or heavy apps. Flashing the latest Global ROM (V10.2.2.0) or a custom ROM like LineageOS 17.1 can leverage the Snapdragon 820 for better performance.
- Q2: How can I fix battery drain on my Mi 5? A: Battery drain may stem from background processes or outdated firmware on the 3000mAh battery. Flashing a clean stock ROM or a debloated ROM like Xiaomi.eu or Pixel Experience can optimize power efficiency.
- Q3: Will the Mi 5 receive Android 9 or newer? A: The gemini variant is officially capped at Android 8.0 with MIUI 10/11. Custom ROMs like LineageOS 17.1 (Android 10) or 18.1 (Android 11) are available on XDA, offering newer Android versions with good support due to the Snapdragon 820.
- Q4: I flashed a ROM for capricorn or natrium on my gemini device and it’s bricked. What do I do? A: If your device is in EDL mode (Qualcomm HS-USB QDLoader 9008), use Mi Flash Tool with the correct gemini Fastboot ROM (e.g., V10.2.2.0.OAAMIXM). Select “clean all” to restore the device. Seek help on XDA Forums if issues persist.
