Download Xiaomi Mi 5s Firmware (capricorn): Fix Bootloop, Lag & Software Issues
This comprehensive guide provides direct download links for the stock firmware flash files and step-by-step instructions to restore your Xiaomi Mi 5s (capricorn). Whether you need to reset your phone, fix bootloop issues, bypass password locks, resolve device freezing, or address other software problems, this guide has you covered. The Mi 5s, featuring a Snapdragon 821 chipset, a 5.15-inch FHD display, and a 3200mAh battery, is a flagship device from 2016 known for its compact design and powerful performance. Note: This article is for the capricorn codename (Mi 5s), not to be confused with other Xiaomi models like Mi 5 (gemini), Mi 5s Plus (natrium), or Mi Note 2 (scorpio).
⚠️ Essential Pre-Flash Checklist
Flashing can lead to errors if not done correctly. Complete this checklist to ensure a smooth process. All data will be wiped, so a backup is critical.
- ✅ Full Data Backup: Save photos, contacts, and files to Mi Cloud, Google Drive, or a PC to prevent data loss.
- ✅ Charged Battery: Ensure your Mi 5s has at least 60% battery to avoid interruptions during flashing.
- ✅ Windows PC: The Mi Flash Tool requires a Windows operating system.
- ✅ Original USB Cable: Use a high-quality USB-C cable for a stable connection to your PC.
- ✅ Unlocked Bootloader: Flashing requires an unlocked bootloader. Use the official Mi Unlock Tool (expect a 7-15 day waiting period).
- ✅ Required Software: Install the latest Mi Flash Tool and Xiaomi USB Drivers.
Understanding the Firmware: Types and Regions
Selecting the correct firmware is crucial to avoid bricking your Mi 5s (capricorn). The capricorn codename is specific to the Mi 5s with the Snapdragon 821 processor, distinct from Mi 5 (gemini, Snapdragon 820) or Mi 5s Plus (natrium, Snapdragon 821).
- Fastboot ROM (.tgz): A full factory image for Mi Flash Tool, ideal for unbricking or reverting to stock MIUI.
- Recovery ROM (.zip): Used with custom recoveries like TWRP for installing custom ROMs like Xiaomi.eu.
- Region Codes:
- CNXM: China version, optimized for local networks but may lack Google Play services.
- MIXM: Global version with Google services and multi-language support.
- EUXM: Xiaomi.eu version, a debloated MIUI ROM with Google services and multi-language support.
Official Firmware Downloads for Mi 5s (capricorn)
These firmware files are sourced from Xiaomi’s official servers or trusted repositories for reliability and security. Ensure you download ROMs for the capricorn codename to avoid compatibility issues.
| Region | MIUI Version | Android | Release Date | Download Link |
|---|---|---|---|---|
| China (CNXM) | V11.0.2.0.OAGCNXM | 8.0 | 2019-10-23 | Fastboot ROM |
| Global (MIXM) | V10.2.3.0.OAGMIXM | 8.0 | 2019-04-26 | Fastboot ROM |
| EU (EUXM) | V11.0.2.0.OAGCNXM | 8.0 | Unknown | Recovery ROM |
TWRP Recovery for Mi 5s (capricorn)
To flash custom ROMs or recovery ROMs via TWRP, install the TWRP custom recovery specific to the Mi 5s (capricorn).
- TWRP Recovery: TWRP-3.2.3-1028-XIAOMI5S-CN – A reliable TWRP version for capricorn. For updates, check TWRP’s official site or XDA Forums.
How to Install TWRP:
- Download the TWRP .img file and rename it to
recovery.img. - Boot your Mi 5s into Fastboot mode (Volume Down + Power).
- Connect to your PC and open a command prompt.
- Flash TWRP by running:
fastboot flash recovery recovery.img. - Boot into recovery:
fastboot boot recovery.img.
Warning: Do not use a TWRP image for other devices (e.g., gemini or natrium), as it will brick your capricorn device. Verify that the TWRP version is capricorn-specific.
Recommended Custom ROMs
The Mi 5s (capricorn) benefits from strong custom ROM support due to its Snapdragon 821 chipset, offering flagship-grade performance. The Xiaomi.eu ROM provides a refined MIUI experience, while other custom ROMs extend Android versions.
- Xiaomi.eu ROM: V11.0.2.0.OAGCNXM Based on Android 8.0 – Offers a lightweight, optimized MIUI experience with Google services.
- LineageOS: Check LineageOS or XDA Forums for builds like LineageOS 17.1 (Android 10) or 18.1 (Android 11), which are well-supported for capricorn due to its high-performance chipset.
- Pixel Experience: Check Pixel Experience or XDA for builds like Pixel Experience 10 or 11, offering a Google Pixel-like interface with enhanced features.
How to Flash: Step-by-Step Instructions
Choose the flashing method based on your firmware type: Fastboot for official .tgz files or Recovery for custom .zip files.
Method 1: The Fastboot Method (Official Stock ROMs)
- Unzip the Firmware: Extract the .tgz file using 7-Zip to obtain a folder with an “images” subfolder and flash scripts.
- Launch Mi Flash Tool: Open the Mi Flash Tool with administrator privileges on your Windows PC.
- Enter Fastboot Mode: Power off your Mi 5s, then press and hold Volume Down + Power until the Fastboot logo appears.
- Connect to PC: Plug your phone into your PC using a USB-C cable.
- Load Firmware: In Mi Flash Tool, click “select” and choose the extracted firmware folder. Click “refresh” to detect your device.
- Choose Flash Option: Select “clean all” for a complete reset (recommended for stability). Avoid “clean all and lock” unless you’re certain of the ROM’s region compatibility.
- Start Flashing: Click “flash” and wait 5-10 minutes. Do not disconnect the phone.
Troubleshooting Tip: If Mi Flash Tool fails to detect your Mi 5s, try reinstalling the Xiaomi USB Drivers or switching to a USB 2.0 port for better connectivity.
Method 2: The Recovery Method (Custom ROMs)
- Install TWRP: Ensure TWRP is installed using the provided TWRP-3.2.3-1028 image. Check XDA for newer versions if needed.
- Transfer ROM: Copy the .zip ROM file (e.g., Xiaomi.eu) to your phone’s internal storage or an SD card.
- Boot into Recovery: Power off your phone, then press Volume Up + Power until the TWRP logo appears.
- Wipe Data: In TWRP, go to “Wipe” > “Advanced Wipe” and select Dalvik/ART Cache, Cache, and Data. Swipe to confirm.
- Install ROM: Return to the main menu, tap “Install,” select the .zip file, and swipe to flash.
- Reboot: Reboot to system after installation completes.
After the Flash: First Boot and Setup
The first boot after flashing may take 10-15 minutes as the system initializes. Don’t interrupt if it seems stuck on the Mi logo. Once booted, follow the setup wizard and restore your data from your backup.
Device-Specific Q&A for the Mi 5s (capricorn)
- Q1: Why does my Mi 5s experience system lag? A: System lag can result from bloatware or heavy apps. Flashing the latest China ROM (V11.0.2.0) or a custom ROM like LineageOS 17.1 can leverage the Snapdragon 821 for better performance.
- Q2: How can I fix battery drain on my Mi 5s? A: Battery drain may stem from background processes or outdated firmware on the 3200mAh battery. Flashing a clean stock ROM or a debloated ROM like Xiaomi.eu or Pixel Experience can optimize power efficiency.
- Q3: Will the Mi 5s receive Android 9 or newer? A: The capricorn variant is officially capped at Android 8.0 with MIUI 11. Custom ROMs like LineageOS 17.1 (Android 10) or 18.1 (Android 11) are available on XDA, offering newer Android versions with good support due to the Snapdragon 821.
- Q4: I flashed a ROM for gemini or natrium on my capricorn device and it’s bricked. What do I do? A: If your device is in EDL mode (Qualcomm HS-USB QDLoader 9008), use Mi Flash Tool with the correct capricorn Fastboot ROM (e.g., V11.0.2.0.OAGCNXM). Select “clean all” to restore the device. Seek help on XDA Forums if issues persist.
